OPT7 Redline Triple Tailgate Light Bar 60" Bundle for Chevy Silverado/GMC Sierra 1500 19-22

MSRP: $189.99
(You save $28.00 )




OPT7 Redline Triple Tailgate Light Bar 60" Bundle with Easy Connect Harness for Chevy Silverado/GMC Sierra 1500 19-22& Sequential Turn Signals


3X More Stopping Power Than The Standard Redline.
The Ultimate In Tailgate Lighting: Command attention with every signal. Bombard those behind you with a volley of 1200 powerful LED's (or 780 on the 48" model). Three complete rows of lights dedicated to maximizing your pickup's presence with an attractive and unique beam of light.

Exclusive "1-2-3" Sequential Turn Signals.
While other tailgate turn signals are just a standard "blink", the Triple Stack gives your truck a distinctive and sporty look with "1-2-3" Sequential amber or red turn signals. The same style used by a certain American-made muscle car and only offered by Redline.

Tinted Windows Making It Hard To See Behind You?
Our extra bright reverse lights will help illuminate the area behind your ride when reversing. Have a backup camera? Say goodbye to grainy videos and see a much clearer picture at night!

Go Ahead, Take It To The Lake.
A lot of folks claim to be waterproof, but Redline actually is. Using a rust-resistant aluminum body and an IP67 waterproof silicone, Redline is protected end to end from any sand, dirt, dust, snow, or water.

The best drilling required!
Made to be as a simple and strong as possible. Simply peel, prep, press onto your pickup and this add-on is as good as factory installed. Comes with a tough-as-nails adhesive enhancer that increases hold strength over 5x. No need to drill, it ain't goin' anywhere.

Spare Tire Access Port Accessibility
Fitment for the Redline Triple LED is based on the amount of Tailgate's available flat surface length-wise. If your vehicle has 48" of available space length-wise across the tailgate then the 48" version will fit nicely. If you have 60" of available space length-wise across the tailgate then the 60" version should be purchased.

Redline Triple Light Bar Coordination:

  • Top Row: Turn Signal/ Hazards
  • Middle Row: Reverse Lights
  • Bottom Row: Brake/ Running Lights

Triple Tailgate Specifications:

  • LED Count: 1200 LEDs on 60-inch.
  • Dimensions: 60-inch (60" x 3/4" x 3/8")
  • Wattage: 3W
  • Voltage: 12v
  • Amperage: 0.25 amp
  • Turn Signal Style: “Sequential”
  • Rated Lifetime: 50,000 Hours
  • Waterproof Rating: IP67
  • Material: Rust-Resistant Aluminum.
  • LED Type: Advanced Bright LED
  • Feature Set: Running | Brake | "1-2-3" Sequential Turn Signals | Reverse | Sequential Hazards
  • Mounting: 3M Adhesive with reinforced applicator
  • Working Temp: -20°F to 170°F
  • Plug’n’Play: 4-Pin Trailer Adapter with Backup wiring
  • Compatible with: 2019+ Chevy Silverado & 2019+ GMC Sierra 1500 - Use Harness
  • Not Compatible with: 2020-2023 Ford F150 Raptor, 2020-2023 Ford Ranger
  • Warranty: 2 Years
You want a better way to tow your vehicle along with our Redline LED Light Bar without a dashboard error? We get it. That's why we've engineered our the Easy Connector to fit seamlessly in your 2019 + Silverado, GMC Sierra 1500's harness. This 6-Pin Extension Connector comes with a custom harness that plugs in-line with your truck's factory wiring so that you can retain the use of your Silverado, GMC Sierra 1500's factory.

We designed this harness and connector specifically for the 2019+ Silverado/ Sierra 1500s. The harness plugs directly into your truck, retaining use of your factory connector in the bed of your truck for easy plug in and go. No more messing with difficult installations or modifications to your truck, just simple installation and quick hookup.
- Provides 4-Pin extension adapter blade-style connector in your truck bed for hassle-free hookup.
- Plugs into factory wiring -no cutting or splicing.
- Custom fit for your ODM vehicle.
- Dashboard Trailer Error Free with OPT7 Redline LED Light Bar

In This Bundle, The Kits Will Include:

Easy Connect Harness Specifications:

  • Wire Gauge: 16 AWG
  • Working Voltage: 12V DC
  • Compatible with 2019+ Chevy Silverado & 2019+ GMC Sierra 1500
  • NOT COMPATIBLE WITH: 2019+ GMC 2500HD,3500HD
  • A Specific fit harness with dual 6 pin connectors to easily hook up two sides in the blink of an eye.
  • Warranty: 90 Days

In This Bundle, The Kits Will Include:

  • 1 x Redline 60" Amber/Red Triple LED Tailgate Brake Light Bar with Reverse & Sequential Turn Signals
  • 1 x OPT7 Redline Easy Connect Harness for 2019+ Silverado/ Sierra 1500

Install Guide:


CA Residents:  WARNING: Cancer and Reproductive Harm -

The Basic 2-Year Limited Warranty Service Our Basic 2-Year Limited Warranty Service offers a convenient process to exchange a eligible confirmed defective Redline Sequential LED Tailgate for a brand new one Features: -Upon submission of a valid claim and conditional approval, the original unit must be packaged and returned to the OPT7 Warranty Center for inspection -The cost of new packaging & return shipping is assigned to the buyer (average cost with USPS Priority is between $20-$40) -Upon delivery, processing, inspection and final approval (2-5 business days) a brand new unit will be shipped to the address provided on your claim form -All new shipments are processed using USPS Standard Shipping (3-5 business days average transit time) -Average processing time is between 1-2 weeks depending on average transit, inspection and processing times. Redline Sequential Triple LED Tailgate (48" & 60") Prime Warranty Add-on (+$15.00) Push the convenience of the Basic 2-Year Limited Warranty Service past the Redline by purchasing the Redline Sequential Triple LED Tailgate Prime Warranty Service. Features: -Immediate shipment (USPS Priority) of a brand new Redline Sequential LED Tailgate upon submission of an approved Warranty claim; all packaging and return costs covered by OPT7. *The new shipment's packaging can be re-used to ship the original unit back to our Warranty Center using the included pre-paid UPS return label *Does not include costs associated with installation or removal -Receiving the new product first allows you to remove and install the new product at the same time; saving you time & money! -Inspection not required. Major manufacturer warranties including the OPT7 Basic Limited Warranty service requires reports of a defect to be confirmed in-house by trained OPT7 technicians. -The Prime Warranty by-passes this requirement which gives you a "Hassle-Free" warranty experience -Average processing time is cut from 1-2 weeks with the Basic Warranty to about 3-5 business days on average with the Prime Warranty
